SF-1
Int. finishing: Ra ≤ 0,4 µm Machined Finish
Ext. finishing: Ra ≤ 0,8 µm Machined Finish
SF-4
Int. finishing: Ra ≤ 0,4 μm Machined Finish + Electropolishing
Ext. finishing: Ra ≤ 0,8 μm Machined Finish + Electropolishing
LL
Int. finishing: Ra ≤ 0,4 μm Mirror Polished
Ext. finishing: Ra ≤ 0,8 μm Mirror Polished
LL-E
Int. finishing: Ra ≤ 0,4 μm Mirror Polished + Electropolishing
Ext. finishing: Ra ≤ 0,8 μm Mirror Polished + Electropolishing
| A | L | ASTM A270 | DIN 32676 | ISO 1127 | Material | Finishing | Code |
|---|---|---|---|---|---|---|---|
| 25,00 | 6,00 | 1/2" - 3/4" | - | - | 1.4435-BN2 | SF-1 | 120Z50050SF1 |
| SF-4 | 120Z50050SF4 | ||||||
| LL | 120Z50050LL | ||||||
| LL-E | 120Z50050LL-E | ||||||
| 34,00 | 6,00 | - | DN 10-15-20 | DN 8-10-15 | 1.4435-BN2 | SF-1 | 120Z5D010SF1 |
| SF-4 | 120Z5D010SF4 | ||||||
| LL | 120Z5D010LL | ||||||
| LL-E | 120Z5D010LL-E | ||||||
| 50,50 | 6,00 | 1" - 1.1/2" | DN 25-32-40 | DN 20-25-32 | 1.4435-BN2 | SF-1 | 120Z50100SF1 |
| SF-4 | 120Z50100SF4 | ||||||
| LL | 120Z50100LL | ||||||
| LL-E | 120Z50100LL-E | ||||||
| 64,00 | 7,00 | 2" | DN 50 | DN 40 | 1.4435-BN2 | SF-1 | 120Z50200SF1 |
| SF-4 | 120Z50200SF4 | ||||||
| LL | 120Z50200LL | ||||||
| LL-E | 120Z50200LL-E | ||||||
| 77,50 | 7,00 | 2.1/2" | - | DN 50 | 1.4435-BN2 | SF-1 | 120Z50250SF1 |
| SF-4 | 120Z50250SF4 | ||||||
| LL | 120Z50250LL | ||||||
| LL-E | 120Z50250LL-E | ||||||
| 91,00 | 7,00 | 3" | DN 65 | DN 65 | 1.4435-BN2 | SF-1 | 120Z50300SF1 |
| SF-4 | 120Z50300SF4 | ||||||
| LL | 120Z50300LL | ||||||
| LL-E | 120Z50300LL-E | ||||||
| 106,00 | 6,35 | - | DN 80 | DN 80 | 1.4435-BN2 | SF-1 | 120Z5D080SF1 |
| SF-4 | 120Z5D080SF4 | ||||||
| LL | 120Z5D080LL | ||||||
| LL-E | 120Z5D080LL-E | ||||||
| 119,00 | 7,90 | 4" | DN 100 | - | 1.4435-BN2 | SF-1 | 120Z50400SF1 |
| SF-4 | 120Z50400SF4 | ||||||
| LL | 120Z50400LL | ||||||
| LL-E | 120Z50400LL-E | ||||||
| 130,00 | 10,00 | - | - | DN 100 | 1.4435-BN2 | SF-1 | 120Z5D100SF1 |
| SF-4 | 120Z5D100SF4 | ||||||
| LL | 120Z5D100LL | ||||||
| LL-E | 120Z5D100LL-E | ||||||
| 167,00 | 11,00 | 6" | - | - | 1.4435-BN2 | SF-1 | 120Z50600SF1 |
| SF-4 | 120Z50600SF4 | ||||||
| LL | 120Z50600LL | ||||||
| LL-E | 120Z50600LL-E |
